导体规格 AWG/mm² |
温度 ℃ |
结构线数 (mm) |
导体数 |
绝缘 (mm) |
外被 (mm) |
外径 (±0.1mm) |
| 10 | 105℃ | 41/0.405 | 2C | 0.76 | 4.67*9.18 | |
| 12 | 105℃ | 65/0.254 | 2C | 0.76 | 4.04*7.92 | |
| 14 | 105℃ | 41/0.254 | 2C | 0.76 | 3.59*7.04 | |
| 16 | 105℃ | 26/0.254 | 2C | 0.76 | 3.17*6.18 | |
| 18 | 105℃ | 41/0.16 | 2C | 0.76 | 2.85*5.56 | |
| 20 | 105℃ | 21/0.18 | 2C | 0.76 | 2.61*5.07 | |
| 22 | 105℃ | 17/0.16 | 2C | 0.76 | 2.43*4.71 | |
| 22 | 105℃ | 7/0.254 | 3G | 0.76 | 2.45*7.04 | |
| 24 | 105℃ | 11/0.16 | 2C | 0.76 | 2.28*4.42 | |
| 24 | 105℃ | 11/0.16 | 3G | 0.76 | 2.28*6.55 | |
| 26 | 105℃ | 7/0.16 | 2C | 0.76 | 2.16*4.17 | |
| 26 | 105℃ | 7/0.16 | 3G | 0.76 | 2.16*6.18 | |
| 28 | 105℃ | 7/0.127 | 2C | 0.76 | 2.06*3.97 | |
| 28 | 105℃ | 7/0.127 | 3G | 0.76 | 2.06*5.87 |
