导体规格 AWG/mm² |
温度 ℃ |
结构线数 (mm) |
导体数 |
绝缘 (mm) |
外被 (mm) |
外径 (±0.1mm) |
| 6 | 105/0.405 | 2C | 1.52 | 3.1 | 23.9 | |
| 6 | 105/0.405 | 3G | 1.52 | 3.1 | 25.1 | |
| 6 | 105/0.405 | 4G | 1.52 | 3.5 | 27.1 | |
| 8 | 65/0.405 | 2C | 1.52 | 2.7 | 20.3 | |
| 8 | 65/0.405 | 3G | 1.52 | 2.7 | 21.6 | |
| 8 | 65/0.405 | 4G | 1.52 | 3.1 | 24 | |
| 8 | 65/0.405 | 5G | 1.52 | 3.5 | 26 | |
| 10 | 41/0.405 | 2C | 1.14 | 2.4 | 16 | |
| 10 | 41/0.405 | 3G | 1.14 | 2.4 | 17 | |
| 10 | 41/0.405 | 4G | 1.14 | 2.4 | 18.3 | |
|
导体规格 AWG/mm² |
温度 ℃ |
结构线数 (mm) |
导体数 |
绝缘 (mm) |
外被 (mm) |
外径 (±0.1mm) |
| 10 | 41/0.405 | 5G | 1.14 | 2.4 | 19.8 | |
| 11 | 82/0.254 | 4G | 0.9 | 1.3 | 15 | |
| 12 | 65/0.254 | 2C | 1.14 | 2.4 | 14.8 | |
| 12 | 65/0.254 | 3G | 1.14 | 2.4 | 15.5 | |
| 12 | 65/0.254 | 4G | 1.14 | 2.4 | 16.8 | |
| 12 | 65/0.254 | 5G | 1.14 | 2.4 | 18.3 | |
| 14 | 41/0.254 | 2C | 1.14 | 2 | 13 | |
| 14 | 41/0.254 | 3G | 1.14 | 2 | 13.6 | |
| 14 | 41/0.254 | 4G | 1.14 | 2 | 14.6 | |
| 14 | 41/0.254 | 5G | 1.14 | 2 | 16.6 | |
|
导体规格 AWG/mm² |
温度 ℃ |
结构线数 (mm) |
导体数 |
绝缘 (mm) |
外被 (mm) |
外径 (±0.1mm) |
| 16 | 26/0.254 | 2C | 0.76 | 1.5 | 9.6 | |
| 16 | 26/0.254 | 3G | 0.76 | 1.5 | 10.1 | |
| 16 | 26/0.254 | 4G | 0.76 | 1.5 | 10.7 | |
| 16 | 26/0.254 | 5G | 0.76 | 1.5 | 12.8 | |
| 18 | 41/0.16 | 2C | 0.76 | 1.5 | 8.9 | |
| 18 | 41/0.16 | 3G | 0.76 | 1.5 | 9.4 | |
| 18 | 41/0.16 | 4G | 0.76 | 1.5 | 10.1 | |
| 18 | 41/0.16 | 5G | 0.76 | 1.5 | 12 |
