| Conductor Size AWG | ℃ | Conductor No./mm | Insulation Thickness (mm) | Jacket Thickness (mm) | OD (±0.1mm) |
| 20 | 60℃ |
1/0.813 7/0.32 |
0.33 | 0.33 |
2.36 2.40 |
| 22 | 60℃ |
1/0.643 7/0.254 |
0.33 | 0.33 |
2.16 2.18 |
| 24 | 60℃ |
1/0.511 7/0.20 |
0.33 | 0.33 |
2.01 2.03 |
| 26 | 60℃ |
1/0.404 7/0.16 |
0.33 | 0.33 |
1.89 1.91 |
| 28 | 60℃ |
1/0.32 7/0.127 |
0.33 | 0.33 |
1.79 1.81 |
| 30 | 60℃ |
1/0.254 7/0.10 |
0.33 | 0.33 |
1.71 1.73 |
